25/27/29FT RIB

(RIGID INFLATABLE Boat)

BRIEF

Our 25-29ft RIB (rigid inflatable boat) is a professional grade, high performance multi use boat that will provide superior buoyancy, unparalleled stability, high performance, and maximum safety in a cutting edge design built to operate in almost any condition. With our hybrid collar design and removable collar bladders, this boat is lighter than a typical side sheeted vessel and keeps the boat inherently stable in all conditions.

Designed not only for superior sea-handling capabilities, the collars have a foam core so that even in the worst situations you will always have enough floatation to provide self-bailing decks. The collars also provide collision protection from other boats or docks when loading or unloading.

Complementing our RIB design is our all aluminum high speed hull that incorporates a 22 degree dead rise aft transitioning to a 48 degree deadrise at the bow. With other class leading hull features like our custom designed interceptor strakes and performance fins you will feel in total control.

BOAT CHARACTERISTICS

Speed: .............................................  60MPH W/ Twin 200HP Outboards

Hull Lengths Available: ................  25', 27', & 29'

Beam with Collar: .........................  10'

Deadrise at Transom: ...................  22 Degrees

Deadrise at Entry: .........................  48 Degrees

All Aluminum Construction: .......  Alloy 5086 H116

Max Engine HP: ..............................  Twin 200HP

Fuel Capacity: ................................  85 - 120 Gallons

Dry Weight: .....................................  Approx. 5,000 lbs

*25FT Model Characteristics Shown



LIFETIME HULL  WARRANTY

CONSTRUCTION DETAILS

Hull Plate: ............ .250"

Side Sheet: .......... .160"

Deck Plate: ........... .190"

Diamond Plate (OP)  .190"

Superstructure:.... .160"

ENGINE OPTIONS

Standard: ................ Dual 150HP 4 Strokes

Options: ....................... Dual 200HP Outboards

                  ................. Single 300HP 4 Stroke



BOAT FEATURES

FAST Closed Cell Foam Buoyancy Stabilizers: The FAST collar system provides superior buoyancy, unparalleled stability and maximum collision protection in a cutting edge, heavy duty package that allows your boat to operate  in the toughest conditions of its class. Manufactured with industry leading equipment and techniques, polyurethane covered foam collars provide a light weight, stable, and seaworthy ride. Used in conjunction with our collar systems our decks are water tight and self bailing which allow them to quickly evacuate any water that may enter the boat. Under the self bailing decks is additional polyethylene foam to achieve maximum flotation and to provide sound deadening for a quieter ride.

As a industry leader, FAST collar systems on our RIB's are designed with a fully enclosed/removable air bladder inside the collar between the outer membrane and polyethylene foam. This air bladder can be built to any size, allowing for different ratios of air to foam in the collar. The air bladder can be removed and replaced in minutes once the zipper that runs full length of the collar is unzipped. This allows the removal and replacement of the air bladder without ever having to remove the collar from the boat.

Hull Scantling Structure: The boats structure is designed with toughness in mind. Using the latest in computer aided design software and vessel computation analysis, our engineering team is leading the industry with modern vessel design. All hull and superstructure components are cut with a computer controlled (CNC) router. The structure of our boats are designed using the marine industry rules and regulations published by LLoyd's Register and ISO.

Performance Fins: With our performance fins, located below the collar, the boat stays flat in the corners and provides unmatched performance while greatly reducing heal.

ABYC Rigging Compliance: We are dedicated to using ABYC rules and regulations during the design and manufacturing of our boats.

Shock Mitigated Flip up Bolster Seating: This boat comes with shock mitigated seating as a standard option. Varying grades of shock mitigation seating are available as options.

BOAT VIDEOS

BOAT PICTURES

OPTIONS

Please call to discuss options. This boat can be ordered with options that are not shown below. The lists shown below are just some of the available options we can design into your platform.

STANDARD FEATURES

Hull Features:

5086 Aluminum Plate, Lifting Strakes, and Performance Fins

Self Bailing Deck with Four Scuppers

3/4" Aluminum Hand Rails

Aluminum Wrapped Polyethylene Foam Under Decks

Removable Center Deck Plate for Fuel Tank Access

Aluminum Welded, Baffled, Epoxy Coated Fuel Tank

Welded In Speed Shoe Pad in Bottom Plate

Anchor Locker

Welded Bow Eye and Welded Stern Eyes

304 Stainless Steel Hardware

SS Internal Lifting Eyes

Four Welded On Cleats

Welded on Anode Mounts

All Aluminum Welded Pipe Arch



Rigging Features:

FAST (Foam Air Stabilized Technologies) Collar System

Epoxy Painted Side Sheets Behind Collar System

Two Sport Marine Grade Seats

Driver and Passenger Shock Mitigated Seating

Navigation Lights

Anchor Light

Tempress Hatches

Locking Glove Box

Fuel Gauge

Tachometer

Compass

Navigation Horn

Two 12V Electrical Plugs

Electric Bilge Pump w/ auto switch 2000GPM

Sacrificial Anode

Fuel Water Separator

Hydraulic Steering

Robust Electrical System with Dedicated Engine and House AGM Batteries

Safety Walk Non-Skid

Four Folding Cup Holders



Standard Trailer: Galvenized Trailer with OTR Straps

Optional Upgrades

Collar Options:

 Color Choice

Rub Strake Color - Grey or Black

Collar Design for 8'-6" Trailer Ability



Other Available Options:

Upgraded Shox or Shockwave Seating

Bimini Top with Canvas Options

Deck Lighting

VHF Radio

Tilt Steering Helm

Exterior Cushion Package

Navigation Package

Radar Package

Stereo System with Four Speakers

SS Cup Holders

Prices and Specifications Subject to Change Without Notice. Photos May Show Optional Equipment

Boat Characteristics are Based on Testing Done by Life Proof Boats -  Customer Realized Values May Vary
